S-C60 I/O Cabinet

Marine Watch Alarm Management

S-C60 I/O Cabinet

The S-C60 I/O Cabinet provides I/O with up to 60 switch input channels for the highly effective and attractive alarm management system Marine Watch S Series.

The system architecture is scalable and can be used in small to medium-sized installations in configurations of several hundred channels.

The I/O cabinets are separate from the panels and communicate to the alarm panel(s) (sold separately) on a standard Ethernet cable. One or several alarm panels can be installed for remote monitoring and response.

or

* 2 x S-AI8 gives a total of 16 flexible analogue input channels.
* 2 x S-DO8 gives a total of 16 digital output channels.

SKU: 1500080 Category: Tag:

Description

The S-C60 I/O Cabinet provides I/O with up to 60 switch input channels for the highly effective and attractive alarm management system Marine Watch S Series.

The system architecture is scalable and can be used in small to medium-sized installations in configurations of several hundred channels.

The I/O cabinets are separate from the panels and communicate to the alarm panel(s) (sold separately) on a standard Ethernet cable. One or several alarm panels can be installed for remote monitoring and response.

Bringing alarm channels from multiple processes and multiple I/O cabinets into Marine Watch S Series reduces risk, and gives the operator a clear view of vessel status.

The S-C60 I/O Cabinet can be supplied in 12 VDC and 24 VDC versions. 8 or 16 analogue input channels can be added by adding one or two of the optional S-AI8 Analogue Inputs, and 8 or 16 digital output channels can be added by adding one or two of the optional S-DO8 Digital Outputs.

Compatible products

This product is compatible with the following products:



Additional information

Size

w 500 x h 600 x d 210 mm
