LT-ACE Annunciator Panel

Remote alarm operator panel Marine Watch Alarm Management

LT-ACE Annunciator Panel

The LT-ACE Annunciator Panel in the highly effective and attractive alarm management system Marine Watch LT Series.

SKU: 1500120 Category: Tags: , ,

Description

The LT-ACE Annunciator Panel in the highly effective and attractive alarm management system Marine Watch LT Series.

  • Auto-detects and self-configures with up to two LT-ONE Alarm Panels
  • Practically unlimited number of LT-ACEs in the network
  • Alarm list combines all LT-ONEs
  • CCTV support
  • Compatible with 200 Series and 400 Series DCUs

Neat and powerful

The Marine Watch LT Series can be used in any unclassed vessel and support more than 100 I/Os with a mix of sensor types. The LT-ONE Alarm Panel carries 19 flexible onboard I/O out of the box, making it a super neat and cost-effective system that is quick to install.
The LT-ONE can be used stand-alone or in combination with the LT-ACE Annunciator Panel that visualizes alarms from up to two LT-ONE Alarm Panels. The LT-ACE automatically self-configures when connected to the same Ethernet network as the LT-ONE.

Additional information

Size

w 167 x h 135 x d 68 mm

Cut out

w 156 x h 124 mm, Access depth 90 mm

Screen

Touch, 5.7", Resolution 640 x 480 pixels

IP

IP56

Power Supply

24/12 VDC, Min 8 VDC, Max 32 VDC
